Electrical & Performance Stats
- Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 480 CCA (Tested at -18°C)
- Reserve Capacity (RC): 75 Minutes (Discharged at 25A down to a 10.5V cut-off)
- Ampere-Hours (AH): 40 Ah (At a 20-hour capacity rate)
Physical & Fitment Stats
- Length: 237 mm (Casing measures 228 mm at the base base)
- Width: 171 mm
- Height: 182 mm (Bottom to top cover)
- Total Height: 208 mm (Including the standard terminal posts)
- Approximate Wet Weight: 13.99 kg
- Group Size / Box Code: A46 / NS50 footprint
- Terminal Assembly / Polarity: Layout C (Positive Left / Right-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/DFP standard taper)
- Base Hold-Down Ledges: End Ledge & Front Ledge (EL & FL)
