Electrical & Performance Stats
- Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 685 CCA (Tested at -18°C)
- Reserve Capacity (RC): 112 Minutes (Discharged at 25A)
- Ampere-Hours (AH): 67 Ah (At a 20-hour capacity rate; listed as 65 Ah in alternative testing footprints)
-
Technology: Enhanced Flooded Battery (EFB SS) optimized for high cyclic demand
Physical & Fitment Stats
- Length: 231 mm (232 mm case base footprint)
- Width: 172 mm (173 mm case variant profile)
- Height: 200 mm (Bottom to top cover)
- Total Height: 220 mm to 225 mm (Including terminal posts depending on testing base)
- Wet Weight: 18.0 kg
- Group Size / Box Code: D23 / Q85 footprint
- Terminal Assembly / Polarity: Layout D (Positive Left / Right-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/STD)
- Base Hold-Down Ledge: Front Ledge (FL) or End Ledge (EL)
