Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 800 CCA (Tested at -18°C)
- Reserve Capacity (RC): 140 Minutes (Discharged at 25A)
- Ampere-Hours (AH): 80 Ah (At a 20-hour capacity rate)
-
Technology: Valve Regulated Lead-Acid (VRLA) with Absorbent Glass Mat (AGM SS)
Physical & Fitment Stats
- Length: 315 mm
- Width: 175 mm
- Height: 190 mm (Bottom to top cover)
- Total Height: 190 mm (Including terminal posts)
- Wet Weight: 24.0 kg
- Group Size / Box Code: N77H / DIN75LH (Commonly referred to as an LN4 footprint)
- Terminal Assembly / Polarity: Layout C (Positive Right / Left-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/STD)
- Base Hold-Down Ledges: EL & FL (End Ledge & Front Ledge)
