- Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 915 CCA (Tested at -18°C)
- Reserve Capacity (RC): 165 Minutes (Discharged at 25A down to a 10.5V cut-off)
- Ampere-Hours (AH): 110 Ah (At a 20-hour capacity rate)
Physical & Fitment Stats
- Length: 315 mm (Case footprint measures 311 mm at the base)
- Width: 175 mm
- Height: 168 mm (Casing base to top cover)
- Total Height: 190 mm (Including the standard terminal posts)
- Approximate Wet Weight: 20.93 kg to 21.32 kg
- Group Size / Box Code: LN4 / N77H
- Terminal Assembly / Polarity: Layout D (Positive Left / Right-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/STD)
- Base Hold-Down Ledges: End Ledge & Front Ledge (EL & FL)
