Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 840 CCA (Tested at -18°C)
- Reserve Capacity (RC): 165 Minutes (Discharged at 25A down to a 10.5V cut-off)
- Ampere-Hours (AH): 90 Ah (At a 20-hour capacity rate)
-
Technology: Sealed Maintenance-Free Calcium/Calcium (SMF CAL)
Physical & Fitment Stats
- Length: 315 mm
- Width: 175 mm
- Height: 175 mm (Bottom to top cover)
- Total Height: 175 mm (Including the integrated terminal posts)
- Group Size / Box Code: LN4 / N77 (Commonly referred to as a standard DIN75L footprint)
- Terminal Assembly / Polarity: Layout C (Positive Right / Left-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/STD)
- Base Hold-Down Ledges: End Ledge & Front Ledge (EL & FL)
