- Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 650 CCA (Tested at -18°C)
- Reserve Capacity (RC): 120 Minutes (Discharged at 25A)
- Ampere-Hours (AH): 75 Ah (At a 20-hour capacity rate)
- Maximum Charging Voltage: 14.8 V at 25°C
- Float Charging Voltage: 13.5 V to 13.8 V at 25°C [1, 2, 3]
Physical & Fitment Stats
- Length: 233 mm
- Width: 173 mm
- Height: 201 mm (Bottom to top cover)
- Total Height: 222 mm (Including terminal posts)
- Wet Weight: ~17.04 kg
- Group Size / Box Code: D23 / NS50
- Terminal Assembly / Polarity: Layout C (Positive Left / Right-Hand Return)
- Terminal Post Type: Standard Automotive Post (SAE/STD)
- Base Hold-Down Ledge: Front Ledge (FL)
