Key Specifications
| Technical Feature | Specification |
| Nominal Voltage | 12V |
| Cold Cranking Amps (CCA) | 680 A (at -18°C) (Some batches rated at 600 A) |
| Amp Hours (Ah / 20-hr) | 75 Ah (Some variants listed at 65 Ah) |
| Reserve Capacity (RC) | 125 Minutes (at 25A) (Some specs list 115 mins) |
| Battery Technology | Sealed Maintenance-Free Calcium (SMF CAL) |
Physical Dimensions & Layout
-
Length: 242 mm
-
Width: 175 mm
-
Case Height / Total Height: 190 mm
-
Wet Weight: Approx. 13.8 kg
-
Terminal Type: Standard Automotive Post (STD / Top Stud - TS)
-
Assembly / Polarity: Assembly "C" (Left-Hand Negative, Right-Hand Positive)
-
Base Ledge: End Ledge & Front Ledge (EL & FL) for European-style bottom-bracket tray clamping
