- Nominal Voltage: 12V
- Cold Cranking Amps (CCA): 500 CCA (Tested at -18°C; sometimes catalogued regionally at 490 CCA)
- Reserve Capacity (RC): 90 Minutes (Discharged at 25A to a 10.5V cut-off)
- Ampere-Hours (AH): 56 Ah (At a 20-hour capacity rate)
Physical & Fitment Stats
- Length: 236 mm
- Width: 128 mm (Slimline casing design)
- Height: 199 mm (Bottom to top cover case height; 200 mm in variant specs)
- Total Height: 219 mm to 220 mm (Including terminal posts)
- Approximate Wet Weight: ~12.7 kg to 13.0 kg
- Group Size / Box Code: NS60 / B24
- Terminal Assembly / Polarity: Layout D (Positive Left / Right-Hand Return)
- Terminal Post Type: Pencil Terminals (JIS/PT)
- Base Hold-Down Ledge: No Ledge (NL)
