Key Specifications
| Technical Feature | Specification |
| Nominal Voltage | 12V |
| Cold Cranking Amps (CCA) | 500 A (at -18°C) |
| Amp Hours (Ah / 20-hr) | 56 Ah |
| Reserve Capacity (RC) | 90 Minutes (at 25A) |
| Battery Technology | Sealed Maintenance-Free Calcium (SMF CAL) |
Physical Dimensions & Layout
-
Length: 236 mm
-
Width: 128 mm
-
Height: 199 mm
-
Total Height (including posts): 219 mm
-
Wet Weight: 11.8 kg
-
Terminal Type: Standard Automotive Post (STD / SAE)
-
Assembly / Polarity: Assembly "C" (Left-Hand Negative, Right-Hand Positive with terminals close to the front edge
